WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
Temperature
The engine temperature sensor is resistive. The display bars will be indicated as per the attached table.
- 8 bars appear on the display, with the letters C (Cold) and H (Hot) plus the temperature icon.
- The high temperature indicator light will illuminate when it reaches 110 °C and will turn off when it returns to 100 °C.
- It will indicate an open circuit when resistance values exceed 900 OHM.
- It will indicate a short circuit when resistance values fall below 2 OHM.
- When an open circuit or a short circuit is detected, bars 1 and 8 plus the LED alarm will ash.
Oil pressure
The low oil pressure indicator will activate when the engine’s internal pressure gauge detects a pressure lower than the alarm value.
Safety belt - Seat
When input 13 (belt/seat input) goes from active (12 V) to inactive (open circuit) and input 15 (handbrake) is inactive at that time (open
circuit), the brake warning beeper and marker light will ash until either input returns to active (12 V) status. It will have to run for 1 minute
after removing the key from the vehicle.
MULTIFUNCTION PANEL
SCALES
TEMP. (ºC)
RES (Ω)
0
0
3030
1 2 43 5 6 7
30
837
45
432
60
235
98
68
75
139
102
60
106
53
110
47
8
140
22
