WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
MAINTENANCE
Recommended inspections
• Check if there are signs of wear on the cam.
• Check if there are signs of wear on the spring.
• Perform a visual inspection of the components.
• Look for wear on the pulleys due to the friction of the transmission belt
- (visual inspection only; xed and sliding pulley).
• Check the wear of the bushings of the sliding pulley (visual inspection
only). If there is excessive wear, you must replace the entire pulley
assembly.
• Check the wear of the shaft both inside and out (visual inspection
only).
WARNING
TO MAINTAIN THE PERFORMANCE OF THE PULLEY,
BE SURE TO CLEAN THE BUSHINGS OF THE PULLEY
WITH A MICROFIBRE TOWEL OR A DRY CLOTH.
CAUTION: DO NOT USE ACETONE TO CLEAN THE
BUSHING.
THE STAINLESS STEEL SHAFT CANNOT BE REMOVED FROM
THE ALUMINIUM FIXED PULLEY WITHOUT DAMAGING THE
PARTS.
Sliding pulley
Bushing
Fixed pulley
1
3
