We reserve the right to modify the product and the design.
MAINTENANCE
Checking the alignment:
1. Run a bar or a rope from the rear wheel to the front.
WARNING
THIS BAR OR ROPE MUST REMAIN PARALLEL
BETWEEN THE TWO POINTS ON THE REAR WHEEL
RIM.
This process will project the ideal point for the front of the steering
wheel.
2. Check if the steering respects the indications in the chart. If not,
you must perform the corresponding alignment.
TECHNICAL INFORMATION
If you have the necessary machinery to do this, do it
mechanically and adjust 0° +/- 0.1°.
The steering wheels should have a divergence of 0° +/-
0.1°.
0° +/- 0.1° 0° +/- 0.1°
