WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
MAINTENANCE
Gear cable
To adjust the play in the gear cable, follow this procedure.
1. Use a wrench to loosen the nut (1).
2. Use a wrench to loosen the nut (2).
3. Adjust from point (3) by turning right or left, until you reach the
required play value.
4. Then tighten the nuts.
TECHNICAL INFORMATION
Nut tightening torque: 12-15 Nm
2
1
3
