Power Supply/RF Board Components
9-22 Force FX Electrosurgical Generator C Service Manual
C69, C77 .1 µF ± 10%, 100 V 204 200 509
C73, C75 33 pF ± 5%, 100 V 204 200 451
C79, C107 1000 pF ± 5%, 100 V 204 200 485
C105, C108 .047 µF ± 20%, 50 V 204 200 517
C119, C126,
C129
6800 pF ± 5%, 100 V 204 200 495
C150, C151,
C158, C159
3900 pF ± 5%, 500 V 204 301 044
C152 3300 pF ± 5%, 500 V 204 105 038
C154, C157 .0047 µF ± 10%, 2000 V 204 200 548
C155, C169 .68 µF, 100 V 204 450 016
C171 10 µF ± 20%, 25 V 204 600 067
C174 470 pF ± 5%, 100 V 204 200 481
Diodes
CR1 1N4007 239 500 013
CR3, CR4,
CR5, CR6,
CR7, CR8,
CR12, CR15,
CR17, CR18,
CR25, CR26,
CR27, CR28,
CR34, CR37,
CR39, CR41,
CR47, CR48,
CR49, CR50
1N4148 239 014 000
CR9 LED, green.2 dia. 239 750 063
CR14, CR16,
CR29
Schottky.6 A, 40 V 239 700 066
Reference
Designator
Description Part Number
To Next Page
