Power Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-23
CR20, CR21,
CR22, CR24,
CR32, CR36,
CR38, CR40,
CR51
Zener 1N5240B, 10 V 239 600 001
CR33, CR42,
CR44, CR45,
CR46, CR52
Zener 1N5233B 239 600 000
Fuses
F1, F2, F3 Fuse, sub-mini 1/2 A 215 100 004
F4 Fuse, 5 x 20 mm, 6.3 A 215 100 041
Relays
K1, K3, K4,
K5, K6, K8,
K9, K10, K11
12 V 230 013 000
K2 6 pole 230 017 006
K7 Relay 1005679
K12, K13,
K14, K15,
K16, K17
Coto-9442 230 017 003
Transistors
Q2 FET N-CH 14 A, 60 V 239 200 014
Q6, Q8, Q9,
Q10
FET TN2404KL 239 200 097
Resistors
R1, R2 9.1 k
:, 1 W 234 204 003
R3, R38, R69 1 M
: ± 5%, 1/4 W 234 024 135
R4 18.2 k
: ± 1%, 1/8 W 234 201 410
R5, R6 30 k: ± 5%, 3 W 234 100 180
R7 91 k
: ± 5%, 1/4 W 234 024 110
Reference
Designator
Description Part Number
To Next Page
