Power Supply/RF Board Components
9-24 Force FX Electrosurgical Generator C Service Manual
R8, R169 390 : ± 5%, 1/4 W 234 024 053
R9 10
: ± 5%, 1 W 234 022 015
R10 63.4 k: ± 1%, 1/8 W 234 201 462
R11, R17,
R20, R25,
R39, R75,
R79, R87,
R92, R101,
R106, R144,
R146, R147,
R152, R155,
R170
1 k
: ± 5%, 1/4 W 234 024 063
R12, R18,
R21, R26,
R131, R136,
R140
51
: ± 5%, 1/4 W 234 024 032
R13, R14,
R15, R45,
R48, R67,
R86, R91,
R93, R99,
R100, R107,
R108, R111,
R112, R122,
R130, R132,
R133, R134,
R137, R142,
R143, R173
10 k
: ± 5%, 1/4 W 234 024 087
R16 4.75 k
: ± 1%, 1/8 W 234 201 354
R19, R109 Thermistor, 10 k:, 25 C 240 003 006
R22, R23 10
: ± 5%, 1/2 W 234 014 068
R24, R34,
R102, R117,
R121, R135
100
: ± 5%, 1/4 W 234 024 039
R27 267
: ± 1%, 1/8 W 234 201 234
Reference
Designator
Description Part Number
To Next Page
