Power Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-25
R28, R54,
R70, R118,
R119, R125,
R126, R128,
R171
4.7 k: ± 5%, 1/4 W 234 024 079
R29 3.32 k
: ± 1%, 1/8 W 234 201 339
R30 1.3 k
: ± 5%, 1/4 W 234 024 066
R32, R33 Thermistor 240 003 005
R35, R52 100 k
: ± 1%, 1/8 W 234 201 481
R36 12.4 k
: ± 1%, 1/8 W 234 201 394
R37 10
: ± 5%, 1/4 W 234 024 015
R40 7.5 : ± 5%, 1/2 W 234 014 065
R41 649
: ± 1%, 1/8 W 234 201 271
R42, R55 10 k
: ± 1%, 1/4 W 234 201 385
R43, R104 68 k: ± 5%, 1/4 W 234 024 107
R44 5.6 M
: ± 5%, 1/4 W 234 024 152
R46 330
: ± 5%, 1/4 W 234 024 051
R47 1.6 k
: ± 5%, 1/4 W 234 024 068
R49, R53 2.67 k
: ± 1%, 1/8 W 234 201 330
R50 511
: ± 1%, 1/2 W 234 204 020
R56 200 k: ± 5%, 1/4 W 234 024 118
R57, R66 110 k
: ± 5%, 1/4 W 234 024 112
R58 39 k
: ± 5%, 1/2 W 234 014 113
R59, R60,
R63, R65,
R71, R72,
R73, R85
2 k
: ± 1%, 1/8 W 234 201 318
Reference
Designator
Description Part Number
To Next Page
