Power Supply/RF Board Components
9-26 Force FX Electrosurgical Generator C Service Manual
R61, R64,
R74, R81
1 k: ± 1%, 1/8 W 234 201 289
R62, R82 499 : ± 1%, 1/8 W 234 201 260
R68 510
: ± 5%, 1/4 W 234 024 056
R76 100
: ± 1%, 2 W 234 400 276
R77 221 : ± 1%, 1/8 W 234 100 181
R78 280
: ± 1%, 1/8 W 234 201 236
R80 62 k
: ± 5%, 1/4 W 234 024 106
R83, R84 249 : ± 1%, 1/8 W 234 201 231
R88 6.8 k
: ± 5%, 1/4 W 234 024 083
R89 5.1 k
: ± 5%, 1/4 W 234 024 080
R90 3.9 k: ± 5%, 1/4 W 234 024 077
R94 56.2 k
: ± 1%, 1/8 W 234 201 457
R95, R151,
R156, R158,
R162, R163,
R165
10 k
: ± 1%, 1/8 W 234 201 385
R96 Trimpot, 5 k
: 236 200 078
R97 301
: ± 1%, 1/4 W 234 201 239
R98 Thermistor, 1 k /25C 5% 240 003 019
R103 47
: ± 5%, 1/4 W 234 024 031
R105, R139,
R141
100 k
: ± 5%, 1/4 W 234 024 111
R110 2.15 k: ± 1%, 1/8 W 234 201 321
R113, R114,
R115,
820
: ± 5%, 1/4 W 234 024 061
R120 3.40 k
: ± 1%, 1/8 W 234 201 340
Reference
Designator Description Part Number
