Power Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-27
R123 270 k: ± 5%, 1/4 W 234 024 121
R124 750
: ± 5%, 1/4 W 234 024 060
R127 3.3 k: ± 5%, 1/4 W 234 024 075
R138 15 k
: ± 5%, 1/4 W 234 024 091
R145, R154,
R157, R161,
R167
5.11 k
: ± 1%, 1/8 W 234 201 357
R148, R149 10 k: ± 1%, 10 W 234 400 275
R150, R153,
R159, R166,
R168
4.32 k: ± 1%, 1/8 W 234 201 350
R160, R164 5.6 M: ± 10%, 2 W 234 204 013
Transformers
T1 Pulse, dual 1025414
T2, T6, T8,
T16, T17
Inductor, current sense 251 300 007
T3 Power switching 251 200 105
T4 RF, molded 3F3 core 251 200 107
T7, T10, T11,
T12
Square core, REM 1019124
T13 Voltage sense 251 300 044
T14, T15 RF choke 251 100 174
Integrated Circuits
U1 AVS1AC 210 800 018
U2, U9, U20,
U26, U32,
U33, U34
LM 393 N 210 300 011
U3, U13, U19 MOSFET driver TSC1427 210 800 012
Reference
Designator Description Part Number
