10 Technical Data
10.1 Datasheet
Model Name CPS SCA50KTL-DO/US-480 CPS SCA60KTL-DO/US-480
DC Input
Max. PV Power
90kW (33kW per MPPT) 90kW (33kW per MPPT)
Max. DC Input Voltage
1000V
DC
Operating DC Input Voltage
Range
200-950V
DC
Start-up DC Input Voltage / Power
330V / 80W
Number of MPP Trackers
3
MPPT Voltage Range
480-850V
DC
540-850V
DC
Max.PV Short-Circuit Current
(Isc x 1.25)
204A (68A per MPPT)
Number of DC Inputs
15 inputs, 5 per MPPT
DC Disconnection Type
Load rated DC switch
DC Surge Protection
Type II SPD, 2800V
C
, 20kA I
TM
(8/20μS)
AC Output
Rated AC Output Power
50kW 60kW
Max. AC Apparent Power
50kVA/55kVA 60kVA/66kVA
Rated Output Voltage
480V
AC
Output Voltage Range
422-528V
AC
Grid Connection Type
3Φ/PE/N (Neutral optional)
Max. AC Output Current
1
@480V
AC
60.2A/66.2A 72.2A/79.4A
Max AC OCPD Rating
110A 125A
Rated Output Frequency
60Hz
Output Frequency Range
2
57-63Hz
Power Factor
>0.99 (±0.8 adjustable)
Current THD
<3%
Max. Fault Current Contribution (1
Cycle RMS)
64.1A
AC Disconnection Type
Load rated AC switch
AC Surge Protection
TypeⅢ MOV, 1240V
C
, 15kA I
TM
(8/20μS)
1) See Chapter 10.3.5 for Max. AC Apparent Power and Max. AC Output Current
2) The "Output Voltage Range" and "Output Frequency Range" may differ according to the specific grid standard.
