3 Installation
This chapter describes the planning and installation procedures for the
SCA50KTL-DO/US-480 and SCA 60KTL-DO/US-480 3-Phase String Inverters.
Please read carefully and install the products following the step-by-step
instructions.
The inverter and other main items are shipped in two separate packages,
consisting of A.) the main inverter enclosure and B.) the wirebox, mounting
bracket, user manual, and accessory kit. Before installation, please check that
the following items are included in the packages:
Table 3-1 Main Items
No.
Item
Q’ty
Note
Box
(1)
Main enclosure of
the PV inverter
1
A
(2)
Wiring box of the
PV inverter
(Standard or
RSD version)
1
Standard Wire-box includes fuses
on both PV string polarity.
RSD Wire-box includes fuses on
the positive PV string polarity only.
B
(3)
Mounting bracket 1
Bracket upon which the PV inverter
is hung and mounted
B
(4)
User manual 1 PV inverter quick install guide
B
(5)
Accessory kit 1
Kit contains all necessary
hardware and accessories for
installation
B
