3.2.3 Installation Space Requirement
The distances between the inverters or the surrounding objects should
meet the following conditions:
NOTICE:
When the inverter is mounted tilted backward at ≤75°
in an outdoor environment, the CPS Shade Cover (SSC-60ST)
accessory must be installed on the inverter to avoid direct sunlight.
NOTICE:
The spacing between two adjacently mounted inverters must be
≥19.7in (500mm). Spacing should be increased for installation
locations with ambient temperature ≥ 45°C. Ensure that the air
space around the inverter is well ventilated. The spacing below the
inverter is intended to ensure the LCD and Keypad height are well
positioned for the user, and may be decreased, however
consideration must be taken for locations known to flood or have
seasonal snow build up.
