Figure 3-21 Internal Connection Points within the Standard wirebox
Figure 3-22 Internal Connection Points within the RSD wirebox
⑤ DC Input fuse holder/terminal
⑥ DC SPD (Surge Protective Device)
⑦ Internal ground terminal(s)
⑧ AC output terminal block
⑨ Negative DC input busbar
⑩ Rapid Shutdown transmitter
