44
Table 3-3 DC Input Specifications (Independent Mode)
Specification (Independent Mode - per MPPT)
Model SCA50KTL-DO/US-480 SCA60KTL-DO/US-480
Max PV Power
33kW
(Combined ≤ 90kW)
33kW
(Combined ≤ 90kW)
Max PV Voltage 1000Vdc 1000Vdc
Start-up
Voltage / Power
330 / 80W 330 / 80W
Operating Voltage 200-950Vdc 200-950Vdc
MPPT Voltage Range 480-850Vdc 540-850Vdc
Maximum PV Current
(Isc x 1.25)
68A 68A
Table 3-4 DC Input Specifications (Parallel Mode)
Specification (Parallel Mode - 3 MPPTs combined)
Model SCA50KTL-DO/US-480 SCA60KTL-DO/US-480
Max PV Power 90kW 90kW
Max PV Voltage 1000Vdc 1000Vdc
Start-up
Voltage / Power
330 / 80W 330 / 80W
Operating Voltage 200-950Vdc 200-950Vdc
MPPT Voltage
Range
480-850Vdc 540-850Vdc
Maximum PV
Current (Isc x 1.25)
204A 204A
