88
Table 6-1 Protection Parameters (IEEE1547, Rule21, and ISO-NE)
Grid Voltage Protection Setting Range
Parameter
name
Description
(Threshold Value of)
IEEE1547 Rule21 ISO-NE
Min Default Max Min Default Max Min Default Max
GridVoltMax1
Level 1 Max. grid
voltage
100 110 135 100 110 135 100 110.00 135
VoltMaxTripTi
me1(S)
Level 1 Max. grid trip
voltage
0 1 655 0 12.5 655 0 2.00 655
GridVoltMax2
Level 2 Max. grid
voltage
100 120 135 100 120 135 100 120.00 135
VoltMaxTripTi
me2(S)
Level 2 Max. grid trip
voltage
0 0.16 655 0 0.16 655 0 0.16 655
GridVoltMax3
Level 3 Max. grid
voltage
100 120 135 100 120 135 100 120.00 135
VoltMaxTripTi
me3(S)
Level 3 Max. grid trip
voltage
0 0.16 655 0 0.16 655 0 0.16 655
GridVoltMin1
Level 1 Min. grid
voltage
30 88 100 30 88 100 30 88.00 100
VoltMinTripTi
me1(S)
Level 1 Min. grid trip
voltage
0 2 655 0 20.5 655 0 2.00 655
GridVoltMin2
Level 2 Min. grid
voltage
30 60 100 30 70 100 30 50.00 100
VoltMinTripTi
me2(S)
Level 2 Min. grid trip
voltage
0 1 655 0 10.5 655 0 1.10 655
GridVoltMin3
Level 3 Min. grid
voltage
30 45 100 30 50 100 30 50.00 100
VoltMinTripTi
me3(S)
Level 3 Min. grid trip
voltage
0 0.16 655 0 1.5 655 0 1.10 655
