Crown FM600 - Table of Contents

Contents
Section 1– Getting Acquainted 1-1
1.1 Your Transmitter 1-2
1.2 Applications and Options 1-3
1.2.1 Stand Alone 1-4
1.2.2 Backup 1-4
1.2.3 Exciter 1-4
1.2.4 Translator 1-5
1.2.5 Satellator 1-6
1.3 Transmitter/Exciter Specifications 1-7
1.4 Receiver Specifications 1-9
1.5 Safety Considerations 1-9
1.5.1 Dangers 1-9
1.5.2 Warnings 1-9
1.5.3 Cautions 1-9
Section 2– Installation 2-1
2.1 Operating Environment 2-2
2.2 Power Connections 2-2
2.2.1 AC Line Voltage Setting 2-2
2.2.2 Fuses 2-3
2.3 Frequency (Channel) Selection 2-4
2.3.1 Modulation Compensator 2-6
2.4 Receiver Frequency Selection 2-7
2.5 RF Connections 2-11
2.6 Audio Input Connections 2-12
2.7 SCA Input Connections 2-13
2.8 Composite Input Connection 2-13
2.9 Audio Monitor Connections 2-14
2.10 Pre-emphasis Selection 2-14
2.11 Program Input Fault Time-out 2-15
2.12 Remote I/O Connector 2-15
iii
