Appendix
Transmitter Output Efficiency
FM600 User’s Manual A-1
Frequency RF Power PA DC Volts PA DC Current Power Input Efficiency
89.7 660 47.3 17.2 813.6 81.1
600 45.1 15.9 717.1 83.7
450 39.4 13.68 539 83.5
300 32.2 11.42 367.7 81.6
150 22.9 8.87 203.1 73.8
60 14.5 6.95 100.8 59.5
97.9 660 49.7 14.86 738.5 89.4
600 47.1 14.12 665.1 90.2
450 40.3 12.55 505.8 89
300 32.4 11.11 360 83.3
150 23 9.22 212.1 70.7
60 14.8 8.26 22.2 49.1
107.9 660 51.1 16.24 829.9 79.5
600 48.8 15.8 771 77.8
450 42 14.56 611.5 73.6
300 34.6 12.83 443.9 67.6
150 26.4 10.91 288 52.1
60 16.2 7.09 129.4 46.4
