Motherboard Jumper Configuration Chart 4.6.1
4-9 Principles of Operation
Jumper FMA “E” FMA “T”
50k-Ohm Input
FMA “T”
600-Ohm Input
FMA “R”
Z1 Short Short Short Short
Z2 Short Short Short Short
Z3 Open Open Short Open
Z4 Open Open Open Open
Z5 Open Open Short Open
Z6 Open Open Open Open
Z7 Open Open Short Open
Z8 Open Open Short Open
Z9 Short Open Open Open
Z10 Short Open Open Open
Z11 Short Open Open Open
Z12 Short Open Open Open
Z13 Short Open Open Open
Z14 Short Open Open Open
Z15 Open Open Open Open
Z16 Open Open Open Open
Z17 Open Open Open Open
Z18 Open Open Open Open
Z19 Open Open Open Open
Z20 Open Open Open Open
Z21 Open Open Open Open
Z22 Open Open Open Open
Z23 Short Short Short Short
Z24 Short Short Short Short
Z25 Short Short Short Short
Z26 Short Short Short Short
Z27 Short Short Short Short
Z28 Short Short Short Short
Z29 Short Short Short Short
Z30 Short Short Short Short
Z31 Open Open Open Open
Z32 Short Open Open Open
Z33 Short Open Short Open
JMP1 Open Open Open Open
JMP2 Open Open Open Open
