ThenextstepistounbolttheRX3’stwinradiators.Youdon’thaveto
disconnectthehosesorremovetheradiators;youjustwantthe
radiatorstobeloosesothatyou’llhaveaccesstothevalvecoverson
topofthecylinderhead.

Unbolttheradiatorsbutleavethem
inplace…don’tdisconnectthe
hoses.


Afteryou’vedonetheaboveactions,removetheaccessportonthe
leftsideoftheenginecrankcase.

Itcomesoffwitha10mmAllenwrench,andinsideofit,you’llsee
anotherAllenreceptacle.Thisisconnecteddirectlytothe
crankshaft,andit’swhatwe’llusetomanuallyrotate
theengine.


Next,removetheviewcapontheleftfrontoftheenginecrankcase,
justforwardoftheportdescribedabove.

Thisistheviewportforviewingthestatorcover,andthisallowsus
topositiontheengineattopdeadcenter.




