Troubleshootingprocedure:Battery charging.
Charging failure of battery
Disconnect the connector clip between the magnetor
conductor bundle and the cable of the complete vehicle,
measure if the resistance between the output conductor ends
of charging coil is satisfactory with a mulimeter.
The resistance is infinite.
The resistance is
satisfactory.
The resistance is below the
standard value.
Open circuit of charging coil or its
output conductor
Switch on the connector clip between
the magetor conductor and the cable of
complete vehicle and switch off the
rectifier or the plug-in between the
rectification regulator and the cable of
the com
p
lete vehicle
Short circuit of charging coil
Measure if the resistance between the
output conductor ends of charging coil
in the connector clip with an ohmmeter
and inspect if the resistance of the
char
g
in
g
coil is satisfactor
y
.
Yes
No
Push the multimeter on the 0-20V DC voltage gear,
measure the voltage between the conductor end (red wire,
generally) from the connector clip to the battery to the
ground
Poor contact or open circuit between the
magentor and the rectifier or between the
ma
g
entor and the rectification re
g
ulato
r
No volta
g
e displa
y
Inspect if the rectifier or the
rectification regulator fails with a
ohmmeter
Voltage display
Open circuit of conductor from the connector
clip and the battery
