Troubleshootingprocedure:Failureofallheadlamps.
Failure of all headlamps
Disconnect the connector clip between the magnetor
conductor bundle and the complete-vehicle cables and
inspect if the electricity is outputted from the output
conduct of magentor illumination coil
Open circuit or short circuit of
magnetor illumination coil or
its out
p
ut conductor
Replace variable voltage rectifier
Illumination of head lamp Illumination failure of head lamp
Internal short circuit of variable
volta
g
e rectifie
r
Disassemble the head lamp
combination and inspect if the
headlamp bulb is burned out
Yes No
Replace the head lamp bulb and inspect if
other head lamp bulbs are burned one by
one
Inspect if the electricity is outputted
from the power input wire of the
illumination switch via the lamp test
method
Yes No
Make direction connection between the power
wire and the output wire of the illumination switch
via one conductor
Open circuit or short circuit of the magnetor
or between the illumination switch lines
Yes
No
Illumination failure after direct
connection
Illumination of headlamp after
short circuit
Poor internal contact of
illumination switch
Open circuit or short circuit between
illumination switch and head lamp
