CSL CS468 - Page 10

CSL CS468 16-Port EPC CLASS 1 GEN 2 RFID READER
USER'S MANUAL, VERSION 2.0.1
Copyright © Convergence Systems Limited, All Rights Reserved
10
CS468INT Specifications:
Physical Characteristics:
Length: 272mm; Width: 142mm; Thickness: 47mm;
Weight: 1.15 Kg
Environment:
Operating Temp: -20
0
C to 50
0
C
Storage Temp: -40
0
C to 85
0
C
Humidity: 95% non-condensing
Output Power
Up to 30dBm at RF connector (after multiplexer box)
Power:
12 Volt supplied via an AC/DC adaptor or IEEE 802.3at
(PoE+) compliant Power Over Ethernet enabled power
source (Max. consumption on PoE: ~ 18W)
RFID Frequency Ranges:
865 – 868 MHz, 902-928 MHz, 952 – 954 MHz bands
Interfaces
LAN TCP/IP ( Configurable to use fixed IP address or
DHCP) or USB
Maximum Tag Read Rate:
300tags/sec. (normal), 150 tags/sec. (dense reader mode)
Accessories:
• USB cable
• GPIO cable
• 12V switching power supply
• Plastic caps for connectors
Order Code:
CS468-NINT
N=1: 865-868 MHz (Europe) & 865-867 MHz (India),
N=2: 902-928 MHz (USA),
N=4: 922-928 MHz (Taiwan),
N=7: 920-925 MHz (China, Australia, Malaysia, Hong Kong etc.),
N=8: 915-922 MHz (Japan)
Restrictions on Use:
Approvals, features and parameters may vary depending on
country legislation and may change without notice
