CSL CS468 User Manual

CSL CS468 16-Port EPC CLASS 1 GEN 2 RFID READER
USER'S MANUAL, VERSION 2.0.1
Copyright © Convergence Systems Limited, All Rights Reserved
105
10.2 Firmware Upgrade Procedure Overview
CSL CS203, CS468 and CS469 Readers have 1 RFID Processor and 1 Network Processor for
RFID application and network application. The application firmware can be upgradable via PC
software provided (RFID FwUpgrade X.X.XX.exe).
The Firmware Compatibility Table shows that current CSL RFID readers with RFID Application
version 1.3.xx and v1.4.xx do not include RFID Bootloader. Therefore if user wants to do firmware
upgrade of RFID Application from v1.3.xx / v1.4.xx to v1.5.xx, user must install the RFID
Bootloader to the reader before upgrading the RFID Application to the latest version (v1.5.xx or
after).
Firmware version for RFID Reader CS203 / CS468 / CS469
RFID App
RFID Bootloader
Network Processor App
Network Processor Bootloader
v1.3.xx
No Bootloader
All, up to v2.18.46
All, up to v2.9.4
v1.4.xx
No Bootloader
All, up to v2.18.46
All, up to v2.9.4
v1.5.xx
v1.0.00 / v1.0.01
v2.18.46
v2.9.4
Network Processor
Application
Bootloader
RFID Processor
Application
Bootloader
CS203 / CS468 / CS469 Reader
Firmware Upgrade
PC Software
(RFID FwUpgrade.exe)
PC
RFID Processor Firmware - Bootloader
(e.g. bootloader_V1001.a79)
RFID Processor Firmware – Application
(e.g. image_V1527.a79)
Network Processor Firmware – Bootloader
(e.g. V2.9.4_F34X_BL.BIN)
Network Processor Firmware – Application
(e.g. V2.18.46_CS203_TCP_to_UART.img)
Firmware files
