CSL CS468 User Manual

CSL CS468 16-Port EPC CLASS 1 GEN 2 RFID READER
USER'S MANUAL, VERSION 2.0.1
Copyright © Convergence Systems Limited, All Rights Reserved
106
The flow diagram for Firmware Upgrade procedure
Check Network Processor Firmware
Version (Bootloader + Application)
Are they up to date?
Upgrade Network Processor Bootloader
Upgrade Network Processor Application
Check RFID Processor Firmware
Version (Bootloader + Application)
No
Yes
Current RFID Processor
Application version
= v1.3.xx / v.1.4.xx?
Upgrade RFID Processor Bootloader
Current RFID Processor
Application version = Latest
version?
Upgrade RFID Processor Application
Firmware upgrade is completed
Yes
No
No
Yes
