CSL CS468 User Manual

CSL CS468 16-Port EPC CLASS 1 GEN 2 RFID READER
USER'S MANUAL, VERSION 2.0.1
Copyright © Convergence Systems Limited, All Rights Reserved
46
6.7 Write Any
This page demonstrates how to write multiple tags EPC ID with automatic increment.
For example, you would like to write 100 tags with EPC ID starting from
ABCD01234567890123456701. The parameters should be as follows:
Num of Tag = 100
Initial Value (decimal) = 1
Mask = ABCD012345678901234567XX (because it needs 2 Hex digits for total 100
numbers)
Then, you should input as below and click the “Start” button to start writing.
Total number of
tags to write
The starting value to
write
EPC Mask
Number of tags
successfully written
Input Fix Q Value
Enable Toggle A/B
Write EPC with
Match / Non Match
Mask
Retry Write EPC
Process
Retry Write EPC
for the tag
