4.4.3 CSL GPIO Board
CSL GPIO board can be used for connecting the CS468 GPIO port to control external devices.
The connection is as below. Please refer to the “CSL GPIO Board Connection Guide” for details.
Connection with CSL GPIO Board
The CSL GPIO board can be used for connecting the CS468 GPIO port to control external
devices. Please refer to the special note “Use of CSL RFID Reader GPIO Control with C# Native
Demo Program” for details.
6 – 48 Vdc
Adaptor
GPIO Port
Device Controlled by
CSL GPIO Board
Signal Detected Input
CSL GPIO Board
