CSL
CS468 16-Port EPC CLASS 1 GEN 2 RFI
D
READER
USER'S
MANU
A
L,
VERSION
2.0.1
Copyright ©
Convergence Systems Limited,
All Rig
hts Reserved
18
4.4.2
GPIO Cable Connection for CS468
Pin
Assign
ment:
The pin assignment of the GPIO cable (DB-9 to open wires) come in the package is as below
.
Connection
2
GPO0
Y
ellow
3
GPO1
Green
4
GP
I1
Red
5
GP
I0
Blue
8,9
GND
Black
Note:
1. Double Shielding (AL
foil + copper braid)
Electrical Specification:
17
19
