CSL CS468 16-Port EPC CLASS 1 GEN 2 RFID READER

USER'S MANUAL, VERSION 2.0.1

CS468 Specifications:

Physical Characteristics:

Length: 272mm; Width: 142mm; Thickness: side-by-side

25mm & 22mm; piggy-back – 47mm; Weight: 1.15 Kg

Environment:

Operating Temp: -20

C to 50

Storage Temp: -40

C to 85

Humidity: 95% non-condensing

Output Power

27dBm at RF connector (after multiplexer box)

Power:

12 Volt supplied via an AC/DC adaptor or IEEE 802.3at

(PoE+) compliant Power Over Ethernet enabled power

source (Max. consumption on PoE: ~ 18W)

RFID Frequency Ranges:

865 – 868 MHz, 902-928 MHz, 952 – 954 MHz bands

Interfaces

LAN TCP/IP ( Configurable to use fixed IP address or

DHCP) or USB

Maximum Tag Read Rate:

300tags/sec. (normal), 150 tags/sec. (dense reader mode)

Accessories:

• RS232 cable (main unit to antenna switching box)

• RF coaxial cable (main unit to antenna switching box)

• USB cable

• GPIO cable

• 12V switching power supply

• Plastic caps for connectors

Order Code:

CS468-N

N=1: 865-868 MHz (Europe) & 865-867 MHz (India),

N=2: 902-928 MHz (USA),

N=4: 922-928 MHz (Taiwan),

N=7: 920-925 MHz (China, Australia, Malaysia, Hong Kong etc.),

N=8: 915-922 MHz (Japan)

Restrictions on Use:

Approvals, features and parameters may vary depending on

country legislation and may change without notice

CSL CS468 User Manual
