Cub Cadet 8454 Service Manual

CHAPTER 4 8454
4-6
D569-W02 May-2003
2. SPECIFICATIONS
2.1 TIGHTENING TORQUES
Middle case
Transmis-
sion case
Rear axle/
brake
75.9 ~ 86.8
57.1 ~ 66.5
94.0 ~ 130.1
17.3 ~ 20.2
57.1 ~ 66.5
35.4 ~ 41.2
17.3 ~ 20.2
35.4 ~ 41.2
57.1 ~ 66.5
35.4 ~ 41.2
91.1 ~ 108.4
91.1 ~ 108.4
57.1 ~ 66.5
57.1 ~ 66.5
44.8 ~ 52.0
144.5 ~ 180.8
191.7 ~ 224.2
lbf·ft
10.5 ~ 12.0
7.9 ~ 9.2
13.0 ~18.0
2.4 ~ 2.8
7.9 ~ 9.2
4.9 ~ 5.7
2.4 ~ 2.8
4.9 ~ 5.7
7.9 ~ 9.2
4.9 ~ 5.7
12.6 ~ 15.0
12.6 ~ 15.0
7.9 ~ 9.2
7.9 ~ 9.2
6.2 ~ 7.2
20.0 ~ 25.0
26.5 ~ 31.0
kgf·m
103.0 ~ 117.7
77.5 ~ 90.2
127.5 ~ 176.5
23.5 ~ 27.4
77.5 ~ 90.2
48.0 ~ 55.9
23.5 ~ 27.4
48.0 ~ 55.9
77.5 ~ 90.2
48.0 ~ 55.9
123.6 ~ 147.1
123.6 ~ 147.1
77.5 ~ 90.2
77.5 ~ 90.2
60.8 ~ 70.6
196.2 ~ 245.2
260.0 ~ 304.1
N·m
M12 (9T)
M12 (6T)
M20
M8 (7T)
M12 (7T)
M10 (7T)
M8 (6T)
M10 (7T)
M12 (7T)
M10 (7T)
M14 (7T)
M14 (7T)
M12 (6T)
M12 (7T)
M16 (9T)
• Inlet bolts and nuts between middle
case and transmission case.
• 17 gear shaft lock nuts.
• Inlet bolts of bearing cover and
bearing case (Main gear shift section).
• Inlet bolts of bearing case (Auxiliary
gear shift section).
• Inlet bolts of main, auxiliary & shuttle
shift covers.
• Inlet nuts of PTO clutch valve.
• Inlet bolt of rear cover (PTO cover).
• Inlet bolt of PTO clutch bracket.
• Inlet bolt of differential bearing case.
• Inlet bolt of lower link bracket.
• Inlet bolt and nuts of hitch.
• Inlet bolt of brake case and rear axle
case.
• Inlet bolt of spiral bevel gear.
• Lock nuts of rear axle.
• Inlet nuts of rear wheel.
