BRAKE
7-5
D569-W02 May-2003
4. STRUCTURE AND OPERATION
4.1 STRUCTURE
(1) Brake Case
(2) Packing
(3) Guide Pin
(4) Brake Cam
(5) O-Ring
(6) Cam Plate (RH)
(7) Cam Plate (LH)
(8) Steel Ball
(9) Steel Ball Sheet
(10) Brake Disc
(11) Plate
(12) Brake Cam Lever (RH)
(13) Brake Cam Lever (LH)
569W701A
