CHAPTER 3 8454
3-4
D569-W03 June-2003
2. SPECIFICATIONS, TIGHTENING TORQUES AND
SPECIAL TOOLS
2.1 SPECIFICATIONS
Clutch pedal
Safety switch
Clutch disc spline boss to shuttle
shaft
Clutch disc surface to rivet
Pressure plate
Item
Free Play
Clearance
Backlash
Depth
Flatness
20 ~ 30 mm
0.79 ~ 1.18 in.
2 ~ 5 mm
0.079 ~ 0.197 in.
-
-
-
Factory Specifications
-
-
2.0 mm
0.079 in.
0.3 mm
0.012 in.
0.2 mm
0.008 in.
Allowable Limit
2.2 TIGHTENING TORQUES
• Inlet bolts between flywheel
housing and clutch housing
• Inlet nuts between flywheel
housing and clutch housing
• Inlet bolts between clutch
housing and middle case
• Inlet nuts between clutch
housing and middle case
• Inlet bolts of clutch cover
• Clutch release fork mounting
bolts
Item
M12 (9T)
M12 (7T)
M12 (9T)
M12 (7T)
M8 (7T)
M8 (7T)
10.3 ~ 117.7
77.5 ~ 90.2
103.0 ~ 117.7
77.5 ~ 90.2
23.5 ~ 27.4
23.5 ~ 27.4
N·m
10.5 ~ 12.0
7.9 ~ 9.2
10.5 ~ 12.0
7.9 ~ 9.2
2.4 ~ 2.8
2.4 ~ 2.8
kgf·m
76.0 ~ 86.8
57.2 ~ 66.5
76.0 ~ 86.8
57.2 ~ 66.5
17.4 ~ 20.2
17.4 ~ 20.2
lbf·ft
Nominal
Diameter (Type)
Tightening Torques
2.3 SPECIAL TOOLS
Clutch center guide
569W301A
