Cub Cadet 8454 Service Manual

ELECTRICAL SYSTEM
8-15
D569-W02 May-2003
4.4 FUSE
A. FUSE BOX DIAGRAM
569W814A
B. CAUTION FOR FUSE REPLACEMENT
There are two kinds of fuse in this tractor. The one is
main fuse which connected to the main wring near the
start motor, the other is sub fuse which fixed in fuse
box. Fuse box is located by clutch pedal. If the main
fuse is failed, it makes impossible to operate any electri-
cal devices of tractor. Replace it with new one. If this
fuse failure continued, investigate the whole wirings
whether there are any short circuit to the ground or not.
In the case of sub fuse failure in fuse box, replace it
with new one. If the fuse failure continued, test the re-
lated devices and wirings and replace if necessary.
Classifi-
cation
Cable
standard
Connec-
tion
terminal
Appli-
cable
fuse
Remark
3
5
11
13
21
6
7
15
36
66
77
AVS3. O R
AVS2. O W
AVS 3. O RL
AVS2. O WR
AVS0. 85 YR
AVS 3. O RW
AVS0. 85 BY
AVS2. O OR
AVS0. 85 RG
AVS0. 85 RW
AVS0. 85YW
5
3
21
6
11
7,13,15,
36,66,77
6
6
6
6
6
25A
20A
10A
10A
20A
10A
10A
10A
6WAY
TERMINAL
