3. SPECIFICATION CON'T
Drive system
Tire size (Std. Tires) Front 9.5 - 16.6
Rear 14.9 - 24.8
Clutch Dry single disc
Steering Hydrostatic steering system
Transmission
12 forward and 12 reverse speeds
Brake Travel Wet disc type
Parking Connected with the traveling brake
Differential Bevel gear
Hydraulic system
Hydraulic lift control system Position, Draft and Mix control
Pump Capacity Main Pump 31.2 L/min (8.2 gal.)
pump
18.7 L/min (5.0 gal.)
Three point hitch SAE Category 1 & 2
1,800 kg (3,968 lb)
No. of remote control valve ports (option) 2-4
PTO
PTO shaft SEA 1 3/8, 6 splines
Revolution (independent PTO) 560 rpm
Min. turning radius ( without Brake)
2,865 mm (112.7 in.)
Traction system
Fixed drawer (or swing drawer Option)
Weight (with ROPS)
1,720 kg (3,792 lb)
Traveling speed ( at rated engine speed with Std tires)
0.37 - 24.6 km/h (0.23 - 15.29 mph)
1-7
