CHAPTER 6 8454
6-74
D569-W02 May-2003
B. FLOW DIAGRAM OF TRANSMISSION OIL
a. STEERING DEVICE & PTO CLUTCH SYSTEM
b. Hydraulic pressure Lift Device
Transmission
Case
(Hydraulic Tank)
Hydraulic filter
Hydraulic pump 2
(7.2 cc/rev)
Power steering
unit
(74 cc/rev)
Steering cylinder
Prior valve
assembly
(7 L/min)
Solenoid valve
assembly
Modulator valve
assembly
PTO clutch
assembly
Transmission
case
(hydraulic tank)
Hydraulic filter
Hydraulic pump 1
(12 cc/rev)
Hydraulic block
(forward external
output port)
Hydraulic cylinder
assembly
