Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8170-42100 HOUSING, HYDRAULIC 1
2 CY-198133-42130 BUSH 65X70X40 2
3 CY-198245-42160 PLUG NPTF1/4 1
4 CY-194556-42220 STRAINER A 1
5 CY-198220-45920 PLUG 3/4-16UNF 2
6 CY-23414-190000 PACKING -19 2
7 CY-23876-010000 PLUG PT1/8,SCREW 2
8 CY-23876-020000 PLUG PT1/4,SCREW 1
9 CY-198240-42130 PACKING, HOUSING 1
10 CY-194150422801 BREATHER, AIR (23) 1
11 CY-198240428101 HINGE, TOP LINK 1
12 CY-194640432011 HEAD ASSY, CYLINDER 1
13 CY-23876-010000 PLUG PT1/8,SCREW 3
14 CY-198220-45920 PLUG 3/4-16UNF 3
15 CY-194555-46380 SPRING 1
16 CY-194555-46730 PLUG 1
17 CY-22217-120000 SPRING WASHER 12 6
18 CY-22217-120000 SPRING WASHER 12 12
19 CY-22217-120000 SPRING WASHER 12 8
20 CY-22312-100180 PARALLEL PIN 10X 18 2
21 CY-22351-040016 SPRING PIN 4X16 1
22 CY-23414-190000 PACKING -19 3
23 CY-24190-130003 STEEL BALL 1
24 CY-24315-000120 O-RING 1B P-12.0 1
25 CY-24315-000140 O-RING 1B P-14.0 2
26 CY-24325-000800 O-RING 1B G-80.0 1
27 CY-26116-120352 BOLT M12X 35 PLATED 5
28 CY-26116-120352 BOLT M12X 35 PLATED 12
29 CY-26116-120352 BOLT M12X 35 PLATED 8
30 CY-26116-120552 BOLT M12X 55 PLATED 1
117
FIG. 64. HYDRAULIC CYLINDER CASE
