Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198133-43310 ROD,PISTON 1
2 CY-198133-43330 PACKING 1
3 CY-198133-43360 SLEEVE 1
4 CY-194180-43410 ROD, PISTON 1
5 CY-198215-44110 CRANK,LIFT 1
6 CY-198133-44210 SHAFT, LIFT 1
7 CY-1A7640-44230 WASHER, 65X82X2 2
8 CY-1A7640-44240 SEAL PLATE 2
9 CY-1A7780-44250 SLEEVE, LIFT SHAFT 2
10 CY-194640-44260 SEAL, SPLINE SHAFT 2
11 CY-198133444101 ARM, LIFT 2
12 CY-1A7780445101 PLATE, P FEEDBACK 1
13 CY-194640445401 RETAINER 1
14 CY-22351-050070 SPRING PIN 5X70 1
15 CY-22351-060016 SPRING PIN 6X16 1
16 CY-22351-080070 SPRING PIN 8X70 1
17 CY-24321-000650 O-RING 1A G-65.0 4
18 CY-26013-120352 BOLT M12X 35 2
119
FIG. 65. PISTON & LIFT CRANK
Copyright 2008 Cub Cadet Yanmar LLC
