Ex Series Ex450

REF

NO.

PART NUMBER DESCRIPTION QTY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A8170-40400 SCV KIT 1 28 CY-198245-46680 BOLT 3/4-16 1

2 CY-194990-22140 NUT W/WASHER 8 3 29 CY-198245-46680 BOLT 3/4-16 4

3 CY-198164-27970 END, ROD 8R 1 30 CY-198245-46680 BOLT 3/4-16 2

4 CY-1A8170-46410 SCV,LINE ASSY 1 31 CY-1A8170-46800 LEVER,SCV 1

5 CY-194464-45930 O-RING 8-1 4 32 CY-1A8170-46850 BRACKET,SCV 1

6 CY-1A8160-46250 COUPLER,QUICK 3/8F 4 33 CY-1A8170-46900 PLATE CMP,LOCK 1

7 CY-198240-46260 SNAP RING 8 34 CY-1A8170-46950 BKT,SCV SUPPORT 1

8 CY-1A8160-46280 PLUG, DUST RED 1 35 CY-1A7880-47750 BOLT,SCV LEVER 1

9 CY-1A8160-46290 PLUG, DUST BLUE 1 36 CY-198220-46200 SPRING 1

10 CY-1A8160-46300 PLUG, DUST YELLOW 1 37 CY-1A8160-65410 LABEL,SCV LEVER 1

11 CY-1A8160-46310 PLUG, DUST GREEN 1 38 CY-1A8170-65420 LABEL,SCV LOCK 1

12 CY-1A8170-46420 HP PIPE,SCV B 1 39 CY-1A8160-65430 LABEL,SCV COUPLER 1

13 CY-1A8170-46440 HP PIPE,SCV C 1 40 CY-194990-85561 KNOB 1

14 CY-1A8170-46460 HP PIPE,SCV A 1 41 CY-22117-080000 WASHER 8 1

15 CY-1A8170-46480 HP PIPE,SCV D 1 42 CY-23414-190000 PACKING -19 2

16 CY-198220-46500 CLAMP 1 43 CY-23414-190000 PACKING -19 4

17 CY-1A8160-46930 SUPPORT,SCV COUPL

1 44 CY-23414-190000 PACKING -19 8

18 CY-23000-035000 CLAMP 35 1 45 CY-23414-190000 PACKING -19 4

19 CY-1A8170-46510 CONNECTOR,3/4UNF-3/

1 46 CY-22417-250300 COTTER PIN 2.5X30 2

20 CY-194464-45930 O-RING 8-1 1 47 CY-26013-080162 BOLT W/WASHER M8

21 CY-1A8170-46550 BKT CMP,SCV LEVER 1 48 CY-26106-060162 BOLT M 6X 16 PLATED 4

22 CY-172122-46590 ELBALL 8 2 49 CY-23414-190000 PACKING -19 2

23 CY-1A8170-46600 SCV ASSY 1 50 CY-26106-080162 BOLT M 8X 16 PLATED 1

24 CY-1A8170-46610 HP PIPE,SCV PUMP 1 51 CY-26106-080202 BOLT M 8X 20 PLATED 4

25 CY-1A8170-46630 HP PIPE,SCV PBYD 1 52 CY-26106-080202 BOLT M 8X 20 PLATED 2

26 CY-1A8170-46650 LINE,SCV DRAINT 1 53 CY-26106-100202 BOLT M10X 20 PLATE

27 CY-198245-46680 BOLT 3/4-16 2 54 CY-26106-100252 BOLT M10X 25 PLATE

125

FIG. 70. SUB CONTROL VALVE

Cub Cadet Ex450 User Manual
