Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198178473001 LEVER,PRESS.CONTROL 1
2 CY-198320473211 PLATE,FRICTION 1
3 CY-198360-47320 ROD, CONTROL 1
4 CY-198320473301 PLATE 1
5 CY-198360-47330 PLATE, CONTROL 1
6 CY-198254-47370 ARM,P CONTROL F.BACK 1
7 CY-198240-47380 SHAFT, CONTROL LEVER 1
8 CY-198320474101 PLATE 1
9 CY-194555-47420 BAR, CONTROL 1
10 CY-198240474301 ARM 1
11 CY-194550-47530 ADJUSTER 1
12 CY-194640-47560 ROD, FEED BACK 1
13 CY-194151-47760 WASHER 12 4
14 CY-194310-47790 PLATE, FRICTION 1
15 CY-194180-51640 CLAMP, WIRE HARNESS 2
16 CY-22137-080000 WASHER 8, POLISHED 2
17 CY-22137-100000 WASHER 10,POLISHED 1
18 CY-22137-100000 WASHER 10,POLISHED 1
19 CY-22272-000070 CIRCLIP E- 7 1
20 CY-22351-050025 SPRING PIN 5X25 1
21 CY-22417-200160 COTTER PIN 2.0X16 1
22 CY-22417-300200 COTTER PIN 3.0X20 2
23 CY-22487-080350 PIN 8X 35 1
24 CY-22522-030130 WOODRUFF KEY 3X13 1
25 CY-24311-000150 O-RING 1A P-15.0 1
26 CY-24311-000150 O-RING 1A P-15.0 1
27 CY-26013-080202 BOLT W/WASHER M8X20 2
28 CY-26013-100162 BOLT M10X 16 2
29 CY-26116-100504 BOLT M10X 50 PLATED 2
30 CY-26716-100002 NUT 10 2
31 CY-26716-100002 NUT 10 4
32 CY-26716-120002 NUT 12 2
129
FIG. 72. HYDRAULIC CONTROL
Copyright 2008 Cub Cadet Yanmar LLC
