Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22140 NUT W/WASHER 8 1
2 CY-194990-22140 NUT W/WASHER 8 2
3 CY-1A7260-60661 SEAL, FRONT BRACKET 1
4 CY-1A7260-60680 URETHANE, GRILLE 1
5 CY-1A7260-60800 CATCH, LOCK 1
6 CY-1A7260-60810 LEVER, GRILLE LOCK 1
7 CY-1A7260-60820 PLATE, BASE LOCK 1
8 CY-1A7260-60870 SEAL, GRILLE SIDE 2
9 CY-1A8160-61300 GRILLE, FRONT 1
10 CY-1A7260613101 NET ASSY, GRILLE 1
11 CY-1A7260-61550 STAY ASSY, LOCK 1
12 CY-194145-61651 NUT, M5 4
13 CY-1A7260-61650 FRAME ASSY, L GRILLE 1
14 CY-1A7260-61660 FRAME ASSY, R GRILLE 1
15 CY-194940-61790 SCREW 5X16 2
16 CY-198071-61890 NUT 6,SPEED 2
17 CY-1A7260-61920 STAY, FRONT GRILLE 1
18 CY-198230-61960 SPRING 1
19 CY-198220-62150 WASHER 2
20 CY-198093-84810 SEAL,FENDER 2
21 CY-22137-060000 WASHER 6, POLISHED 2
22 CY-22137-080000 WASHER 8, POLISHED 1
23 CY-22137-120000 WASHER 12,POLISHED 1
24 CY-22157-060000 WASHER 6 2
25 CY-22157-060000 WASHER 6 2
26 CY-22157-060000 WASHER 6 4
27 CY-22859-500202 SCREW, 5.0 X 20 2
28 CY-26106-060122 BOLT M 6X 12 PLATED 2
29 CY-26106-060122 BOLT M 6X 12 PLATED 4
30 CY-26106-060162 BOLT M 6X 16 PLATED 12
31 CY-26106-080122 BOLT M 8X 12 PLATED 2
32 CY-26346-060002 U-NUT M 6 PLATED 2
153
FIG. 88. FRONT GRILLE
