Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22130 NUT W/WASHER 6 2
2 CY-198461-60590 BOLT 6* 20 3
3 CY-198461-60590 BOLT 6* 20 4
4 CY-1A7780614101 LOWER COVER L.H. CMP 1
5 CY-1A7780614201 LOWER COVER R.H. CMP 1
6 CY-198138-61531 COVER 1
7 CY-1A7780-61540 COVER,DASHBOARD 1
8 CY-1A7780-61550 SUPPORT,DASHBOARD 2
9 CY-1A8170-61560 TRIM 1700 1
10 CY-1A7780-61600 SUPPORT,INSTRUMENT 1
11 CY-194448-61620 GROMMET 20.5 1
12 CY-194167-61650 NUT 5008 4
13 CY-194167-61650 NUT 5008 6
14 CY-198133-61690 COLLAR 10.5X17 2
15 CY-194940-61790 SCREW 5X16 4
16 CY-194940-61790 SCREW 5X16 6
17 CY-198071-61890 NUT 6,SPEED 2
18 CY-22117-060000 WASHER 6 2
19 CY-26106-080122 BOLT M 8X 12 PLATED 2
20 CY-26106-080162 BOLT M 8X 16 PLATED 4
21 CY-26106-100202 BOLT M10X 20 PLATED 4
22 CY-26587-060352 SCREW M6X35 2
157
FIG. 90. DASHBOARD
Copyright 2008 Cub Cadet Yanmar LLC
