Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198220-11510 BOLT 12X27 12
2 CY-198220-11510 BOLT 12X27 12
3 CY-1A8160-65860 TAPE,REFLECTION 2
4 CY-1A8170-85010 ROPS ASSY 1
6 CY-1A8160-85070 BOLT 1/2-20X2.25 2
7 CY-1A8160-85080 NUT 1/2-20 2
10 CY-1A8160-85200 WASHER 1/2 2
12 CY-1A8160-85060 POLY CYLINDER 1
13 CY-1A8160-85070 BOLT 1/2-20X2.25 1
14 CY-1A8160-85080 NUT 1/2-20 1
15 CY-1A8160-85090 BOLT 1/2-13X1.25 1
16 CY-1A8160-85100 WASHER 2
17 CY-1A8160-85110 NUT 1/2-13 1
18 CY-1A8160-85120 HITCH PIN CMP 1
19 CY-1A8160-85200 WASHER 1/2 1
21 CY-1A8160-85060 POLY CYLINDER 1
22 CY-1A8160-85070 BOLT 1/2-20X2.25 1
23 CY-1A8160-85080 NUT 1/2-20 1
24 CY-1A8160-85090 BOLT 1/2-13X1.25 1
25 CY-1A8160-85100 WASHER 2
26 CY-1A8160-85110 NUT 1/2-13 1
27 CY-1A8160-85120 HITCH PIN CMP 1
28 CY-1A8160-85200 WASHER 1/2 1
29 CY-1A8170-85500 PLATE ASSY, BASE L 1
30 CY-1A8170-85550 PLATE ASSY, BASE R 1
31 CY-198220-85290 BOLT 16*40 4
175
FIG. 101. SAFETY FRAME
Copyright 2008 Cub Cadet Yanmar LLC
