Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
REF
NO.
PART NUMBER DESCRIPTION QTY
1 N/A REMOTE KIT, REAR 1P 1 41 CY-41856-020530 PACKING, 2053 1
2 CY-1A8170-17870 BOLT, JOINT 3/4-16 1 42 CY-1A7780-46750 SHAFT,R REMOTE LE
V
1
3 CY-194990-22140 NUT, M8 2 43 CY-1A7780-46790 BRACKET, REMOTE P
O
1
4 CY-1A8170-33150 PEDAL, DIFF.LOCK 1 44 CY-1A7780-47510 BRACKET ASSY, R 1
5 CY-194464-45930 PACKING, 8-1 2 45 CY-1A7780-47570 ROD, R REMOTE LEV
E
1
6 CY-1A8160-46250 COUPLER,QUICK 3/8F 2 46 CY-1A7780-47710 LEVER ASSY, B REMO 1
7 CY-198240-46260 RING, SNAP 4 47 CY-24550-014100 BEARING, 14 X 10 2
8 CY-198240-46280 PLUG, DUST 2 48 CY-1A8170-47750 BRACKET, R REMOTE 1
9 CY-198220-46500 CLAMP 1 49 CY-1A8170-47780 COLLER, 15X25X50.2 1
10 CY-1A7780-46530 CONNECTOR ASSY,G3/
8
2 50 CY-1A8170-48210 HP PIPE,R REMOTE P 1
11 CY-24311-000140 PACKING, P 14.0 2 51 CY-1A8170-48230 HP PIPE,R REMOTE C 1
12 CY-198245-46680 JOINT, 3/4-16 2 52 CY-1A8170-48250 LINE, R REMOTE T 1
13 CY-198442-46702 SCV ASSY, 1 53 CY-1A8170-48510 LINE, R REMOTE A1 1
15 CY-178076-04140 SPRING 1 54 CY-1A8170-48550 LINE, R REMOTE B1 1
16 CY-178076-04150 COVER 1 55 CY-198240-48780 STAY, REAR PIPE 1
17 CY-178076-04310 COVER 1 56 CY-1E4130-51400 GRIP, LEVER 1
18 CY-198165-48560 PLUG, 9/16 2 57 CY-1A8170-65670 LABEL, R REMOTE PO 1
19 CY-194850-49290 O-RING, 6-1 2 58 CY-1A8170-65680 LABEL,R REMOTE LE
V
1
20 CY-194850-49340 PLATE, SEAL 2 59 CY-22137-060000 WASHER, 6 2
21 CY-194850-49380 COVER, CHECK 1 60 CY-22157-060000 WASHER, 6 2
22 CY-194850-49400 VALVE, CHECK 1 61 CY-22351-050032 PIN, 5.0A X 32 1
23 CY-194850-49410 SPRING, SUCTION 1 62 CY-22351-080032 PIN, 8.0A X 32 1
24 CY-194850-49440 PIN, SPRING 2X9 1 63 CY-22417-160160 PIN, 1.6 X 16 2
25 CY-194850-49450 PACKING(DETENT 1 64 CY-22417-250300 PIN, 2.5 X 30 1
26 CY-194850-49460 HOLDER, DETENT 1 65 CY-23000-035000 CLAMP, HOSE 35 1
27 CY-194850-49480 DETENTE 1 66 CY-23414-180023 GASKET, 18 X 1.0 6
28 CY-194850-49490 SPRING, DETENTE 1 67 CY-23414-190000 GASKET, 19 X 1.0 4
29 CY-172510-74410 SEAL, DUST 2 68 CY-23414-190000 GASKET, 19 X 1.0 3
30 CY-172510-74440 RETAINER(SPRING A 1 69 CY-23857-120000 BOLT, JOINT 12 3
31 CY-172510-74450 RETAINER(SPRING B 1 70 CY-26013-140252 BOLT, 14 X 25 2
32 CY-172510-74471 COVER, 4P 1 71 CY-26106-060162 BOLT, 6 X 16 2
33 CY-22287-080000 WASHER, 8 4 72 CY-26106-060202 BOLT, 6 X 20 2
34 CY-24190-050001 BALL, 5/32 2 73 CY-26106-080162 BOLT, 8 X 16 2
35 CY-24190-070001 BALL, 7/32 1 74 CY-26106-100252 BOLT, 10 X 25 1
36 CY-26450-060102 BOLT, 6 X 10 2 75 CY-26106-100252 BOLT, 10 X 25 2
37 CY-26450-060802 BOLT, 6 X 80 2 76 CY-26106-100302 BOLT, 10 X 30 1
38 CY-26450-080302 BOLT, 8 X 30 4 77 CY-26116-120252 BOLT, 12 X 25 1
39 CY-41850-000140 PACKING, 14.0 2 78 CY-198327-48750 BOLT S COMP 1
40 CY-41851-000140 PACKING, 14.0 1 79 CY-23414-190000 PACKING - 19 2
179
FIG. 103. REAR REMOTE VALVE 1P
