Ex Series Ex450

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-129407-32000 PUMP ASSY, LUB.OIL 1

14 CY-129150-32020 GASKET, PUMP 1

15 CY-26450-060252 BOLT, M6X25 4

16 CY-129457-34800 DIPSTICK, LUB.OIL 1

17 CY-121520-34810 GUIDE, DIPSTICK 1

18 CY-129150-35042 GASKET, PIPE 1

19 CY-129550-35090 PIPE ASSY, OIL INLET 1

24 CY-26014-080162 BOLT M 8X 16 1

25 CY-26106-080352 BOLT M 8X 35 PLATED 2

26 CY-119802-35100 BRACKET ASSY, FILTER 1

27 CY-119802-35110 BRACKET, FILTER 1

28 CY-129100-35140 STUD 1

29 CY-129150-35111 GASKET, (NON-ASB.) 1

30 CY-129150-35153 FILTER 80X80L 1

31 CY-26106-080202 BOLT M 8X 20 PLATED 3

32 CY-114250-39450 SWITCH, OIL PRESSURE 1

33 CY-124160-39140 BOLT, JOINT M10 1

34 CY-119802-39450 PIPE ASSY, LUB.OIL 1

35 CY-129005-59830 BOLT ASSY, JOINT 1

36 CY-22190-080002 SEAL WASHER 8S 1

37 CY-23857-030000 JOINT BOLT 3 1

38 CY-22190-080002 SEAL WASHER 8S 1

39 CY-22190-100002 WASHER, 10 2

40 CY-26366-060002 NUT M 6 1

FIG. 11. LUBRICATING OIL SYSTEM
