Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129659-42040 PUMP ASSY, WATER 1 25 CY-129655-44740 FAN, COOLING 1
2 CY-129150-42059 PACKING 1 26 CY-129030-44760 SPACER, FAN 1
4 CY-129263-42120 PLATE 1 27 CY-26106-060502 BOLT M 6X 50 PLATED 4
8 CY-129150-42301 FLAGNE, C. W. PUMP 1 28 CY-129155-49801 THERMOSTAT 1
9 CY-129054-42320 O-RING 1 29 CY-129150-49811 GASKET, THERMOST
1
11 CY-129555-44750 STUD 2 30 CY-129795-49551 GASKET, COVER 1
13 CY-129916-49740 PLUG, R03 2 31 CY-129350-49560 COVER, THERMOSTA
1
14 CY-24358-240310 O-RING, 5 24031 1 32 CY-26306-080002 NUT, M8 2
15 CY-26106-060202 BOLT M 6X 20 PLATED 2 33 CY-119620-49290 COCK ASSY 1
16 CY-26116-060162 BOLT 6X16 3 37 CY-121450-42450 PLUG M16 1
17 CY-26577-060142 SCREW M 6X 14 3 38 CY-124465-44950 GASKET, 16 1
18 CY-129486-42050 GASKET, WATER PUMP 1 39 CY-124250-49351 THERMOMETER 1
19 CY-23414-080000 GASKET 8, ROUND 1 40 CY-129150-49360 GASKET 10 1
20 CY-26106-080122 BOLT M 8X 12 PLATED 1 41 CY-129263-49610 PIPE, WATER A 1
21 CY-26106-080552 BOLT M 8X 55 PLATED 3 43 CY-124722-59050 CLIP, HOSE 2
22 CY-26106-080602 BOLT M 8X 60 PLATED 1 44 CY-129263-49620 PIPE, WATER B 1
23 CY-129550-42350 V-PULLEY, WATER PUM 1 46 CY-124722-59050 CLIP, HOSE 4
24 CY-129052-42290 V-BELT 1
23
FIG. 12. COOLING WATER SYSTEM
Copyright 2008 Cub Cadet Yanmar LLC
