Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-729604-53200 VALVE ASSY,INJECTION 4
2 CY-129604-53000 VALVE ASSY,INJECTION 4
5 CY-114250-53080 NUT, CASE 4
6 CY-119802-53100 HOLDER ASSY, NOZZLE 4
11 CY-114250-53120 SPRING, NOZZLE 4
12 CY-114250-53130 SEAT, SPRING 4
13 CY-114250-53140 PLATE, STOP 4
14 CY-114250-53210 PIN 8
15 CY-119803-53800 SHIM SET 4
42 CY-129633-52110 BRACKET, PUMP 1
43 CY-129633-55620 STAY, FILTER 1
44 CY-26106-080142 BOLT 8X 14 PLATED 2
45 CY-26106-080162 BOLT M 8X 16 PLATED 2
46 CY-129150-59120 RETAINER, PIPE 1
49 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
50 CY-129550-59120 RETAINER, PIPE 1
53 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
55 CY-129601-59810 PIPE ASSY, INJECTION 1
59 CY-129601-59820 PIPE ASSY, INJECTION 1
63 CY-129601-59830 PIPE ASSY, INJECTION 1
67 CY-129601-59840 PIPE ASSY, INJECTION 1
72 CY-119802-59550 PIPE ASSY, RETURN 1
73 CY-124722-59050 CLIP, HOSE 2
74 CY-119802-59560 PIPE, FUEL RETURN 1
75 CY-129486-59581 PIPE ASSY, RETURN 3
76 CY-124722-59050 CLIP, HOSE 6
78 CY-119593-59581 CAP 1
79 CY-124060-77680 CLAMP 10 1
29
FIG. 15. FUEL INJECTION VALVE
Copyright 2008 Cub Cadet Yanmar LLC
