Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129659-12520 CLEANER ASSY, AIR 1
2 CY-129906-12520 ELEMENT 6, CLEANER 1
3 CY-129418-12530 MARK 2
4 CY-129900-12530 COVER ASSY 1
5 CY-119808-12540 VALVE, UNLOADER 1
6 CY-119005-12571 ELEMENT ASSY,INNER 1
7 CY-129612-12650 MARKING,(W) 1
8 CY-129052-13550 GASKET,NOZZLE 1
9 CY-129263-44510 TANK ASSY, SUB 1
10 CY-121450-44531 CAP 1
11 CY-23065-070180 PIPE 7X 180 1
12 CY-124450-44560 CLAMP 1
13 CY-121470-44581 GASKET 1
14 CY-129659-44510 RADIATOR ASSY 1
15 CY-129467-44580 MOUNT RUBBER 2
16 CY-129107-44590 CAP, RADIATOR 1
17 CY-129467-44590 COLLAR 2
18 CY-129956-44730 SEAL,RADIATOR 4
19 CY-119255-44660 RUBBER 2
20 CY-172A38-03201 LABEL,SUB-TANK 1
21 CY-129550-49101 COCK ASSY, 2-WAY 1
22 CY-129150-49081 COCK, DRAIN 1
23 CY-119225-52102 PUMP ASSY, FUEL FEED 1
24 CY-129004-55612 BRACKET,FUEL FILTER 1
25 CY-119802-55700 SEPARATOR ASSY 1
26 CY-129100-55690 RING, RETAINING 1
27 CY-119802-55710 ELEMENT 1
28 CY-119802-55730 CUP ASSY(SERVICE PAR 1
29 CY-24311-000160 O-RING 1A P-16.0 1
30 CY-24321-000650 O-RING 1A G-65.0 1
31 CY-119802-55801 FILTER, FUEL 1
32 CY-124550-77030 COVER, TERMINAL 1
33 CY-129211-77920 TIMER 1
34 CY-129263-93100 LOCK, BONNET 1
35 CY-26106-060122 BOLT M 6X 12 PLATED 2
36 CY-26106-080302 BOLT M 8X 30 PLATED 2
37 CY-26106-080702 BOLT M 8X 70 PLATED 1
38 CY-26306-080002 NUT 2
39 CY-26756-060002 LOCK NUT 6 1
40 CY-114110-07760 LABEL, FUEL OIL 1
39
FIG.1. ENGINE ACCESSORIES MOUNTING
Copyright 2008 Cub Cadet Yanmar LLC
