Ex Series Ex450

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-7A7780-01110 LEVER KIT, CONTROL 1

2 CY-194740-00160 WASHER 10, CONICAL 4

3 CY-1A7780-01110 LEVER ASSY, CONTROL 1

4 CY-198165-01130 PLATE, FRICTION 1

5 CY-198220-01140 BRACKET, LEVER 1

6 CY-194150-01270 SPACER 20 1

7 CY-198242-01350 LEVER,ACCELRTR.LINK 1

8 CY-194145-61570 WASHER 10 1

9 CY-22157-100000 WASHER 10 1

10 CY-26756-100002 LOCK NUT M10 PLATED 1

11 CY-26986-100002 LOCK NUT 10 1

12 CY-198253-01190 KNOB, THROTTLE LEVER 1

13 CY-1A7780-01320 ROD,ACCELERATOR 1

14 CY-198240-01400 PEDAL, THROTTLE 1

15 CY-24550-014200 BUSH 14X20 1

16 CY-198240-01450 ROD, THROTTLE LINK 1

17 CY-198240-01470 BOLT M10 1

18 CY-194750-04400 SPRING, RETURN 1

19 CY-22137-080000 WASHER 8, POLISHED 1

20 CY-22137-080000 WASHER 8, POLISHED 2

21 CY-22137-100000 WASHER 10,POLISHED 1

22 CY-22217-100000 SPRING WASHER 10 1

23 CY-22417-250300 COTTER PIN 2.5X30 1

24 CY-22417-250300 COTTER PIN 2.5X30 2

25 CY-26106-080162 BOLT M 8X 16 PLATED 2

26 CY-26716-080002 NUT M 8 2

FIG. 3. ACCELERATOR LEVER
