Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8170-14700 R4 TIRE KIT, FRONT L 1
2 CY-1A8170-14710 R4 TIRE 10-16.5 1
3 CY-1A8170-14730 R4 WHEEL F 1
4 CY-1A8170-14800 R4 TIRE KIT, FRONT R 1
5 CY-1A8170-14710 R4 TIRE 10-16.5 1
6 CY-1A8170-14730 R4 WHEEL F 1
7 CY-1A8170-14210 STUD, M14X27 12
66
FIG. 25. FRONT WHEEL TIRE (BAR)
Copyright 2008 Cub Cadet Yanmar LLC
