PART NUMBER DESCRIPTION QTY

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-129900-07900 LIFTER, ENGINE 1 32 CY-119625-11880 SEAT, NOZZLE 4

2 CY-26106-080142 BOLT 8X 14 PLATED 2 33 CY-129004-11900 RETAINER, NOZZLE 4

3 CY-129601-11241 SHAFT ASSY, ROCKER 1 34 CY-120270-54410 WASHER, INJECTOR 4

4 CY-129601-11251 SHAFT, ROCKER ARM 1 35 CY-22351-060012 SPRING PIN 6X12 2

6 CY-119802-11260 SUPPORT, ARM A 2 36 CY-26106-080252 BOLT M 8X 25 PLATED 3

7 CY-119802-11270 SUPPORT, ARM B 3 37 CY-26106-080352 BOLT M 8X 35 PLATED 4

8 CY-129150-11280 SPRING, SHAFT 4 38 CY-26106-080502 BOLT M 8X 50 PLATED 7

9 CY-129004-11650 ARM KIT, ROCKER 8 39 CY-124160-01751 COVER, FILLER 1

10 CY-129150-11230 SCREW, VALVE ADJUST 8 40 CY-129601-11350 BONNET ASSY, HEAD 1

12 CY-129150-11750 NUT, M8 8 41 CY-129004-03010 PLATE, BAFFLE 1

13 CY-26226-080182 STUD M 8X 18 PLATED 3 42 CY-129150-03070 BAFFLE, BREATHER 1

14 CY-129150-11370 CAP, VALVE 8 43 CY-119802-03110 PLATE, CENTER 1

15 CY-129604-11700 HEAD ASSY, CYLINDER 1 44 CY-119802-03121 COVER, DIAPHRAGM 1

20 CY-27241-400000 PLUG 40 2 45 CY-119802-03130 DIAPHRAGM 1

21 CY-129005-11100 VALVE, INTAKE 4 46 CY-119802-03141 SPRING, DIAPHRAGM 1

22 CY-129100-11112 VALVE, EXHAUST 4 48 CY-129601-11310 GASKET, BONNET 1

23 CY-129795-11120 SPRING, VALVE 8 49 CY-22857-500100 SCREW, M5X10 4

24 CY-129795-11180 RETAINER, SPRING 8 50 CY-22857-500100 SCREW, M5X10 4

25 CY-121400-11340 SEAL, VALVE STEM 4 51 CY-124160-11360 KNOB 3

26 CY-124460-11340 SEAL, VALVE STEM 4 52 CY-24311-000120 PACKING, P 12.0 3

27 CY-27310-080001 COTTER, 8 8 53 CY-24311-000320 O-RING 1A P-32.0 1

29 CY-120130-11860 GUIDE, VALVE 4 54 CY-119803-77830 HARNESS, GLOW PLUG 1

30 CY-129150-11810 GUIDE, EXHAUST VALV

4 55 CY-129008-77800 PLUG, GLOW 4

31 CY-119802-11870 PROTECTOR, NOZZLE 4 56 CY-129604-77821 CONNECTOR, GLOW PLU

FIG. 4. CYLINDER HEAD & BONNET
